ECo110P/700 FLOW katuseventilaator

ECo110P/700 FLOW katuseventilaator

Kasutusalad: Isoleeritud laeventilaator FLOW mütsiga radooni või ökotualeti jaoks. Energiasäästlik EC-mootor. Juhtimine välise 0–10 V juhtsignaali kaudu (DUC-ist, VILPE välisest ökokontrollerist või VILPE Eco Ideal Wirelessist). Maksimaalne vooluhulk 135 l/s.

Mõõtmed: Ühendus Ø 110, välisläbimõõt 160 mm, kinnituskomplekt 300 x 300 mm.
Sisaldab: Laeventilaator, kinnitusklamber, kinnituskruvid, paigaldus-, kasutus- ja hooldusjuhend.
Color
Product number350262
LVI Code7820330
EAN Code6410457726448
Color | RR33 | RAL9005
Weight Gross: 6.633kg, Net: 5.537kg
Product number350261
LVI Code7820329
EAN Code6410457726486
Color | RR33 | RAL7040
Weight Gross: 6.606kg, Net: 5.51kg
Product number350264
LVI Code7820331
EAN Code6410457726455
Color | RR32 | RAL8019
Weight Gross: 6.633kg, Net: 5.537kg
Product number350267
LVI Code7820333
EAN Code6410457726462
Color | RR23 | RAL7024
Weight Gross: 6.633kg, Net: 5.537kg
Product number350268
LVI Code7820334
EAN Code6410457726479
Color | RR29 | RAL3009
Weight Gross: 6.633kg, Net: 5.537kg
Product number350269
LVI Code7820335
EAN Code6410457726493
Color | RR750 | RAL8004
Weight Gross: 6.633kg, Net: 5.537kg
Product number35026D
LVI Code7820618
EAN Code6410457726509
Color | RR2H3 | RAL7016
Weight Gross: 6.633kg, Net: 5.537kg
SKU: N/A Categories: ,
Share product page
Print pdf
Duct size110 Ø
Voltage230V/50Hz
Current0,75 A
Rotation speed (rpm)3200 rpm
Power83 W
Fan typeEC

Performance data graphs

VILPE ECo FLOW 110 - ISO 5801:2017

Air density: 1.2

10V
8V
7V
6V
5V
4V
3V
2V
10V
8V
7V
6V
5V
4V
3V
2V
10V
8V
7V
6V
5V
4V
3V
2V

Download CAD Models

Download DWG-file
vilpe-flow-eco-110p-700-netti.dwg
MagiCAD file

Materials & Installation

Send document by email

  • This field is for validation purposes and should be left unchanged.

Certificates

Product categories: Katuseventilaatorid, P-seeria katuseventilaatorid
