E220P/Ø160/700 XL katuseventilaator
E220P/Ø160/700 XL katuseventilaator - Image 2

E220P/Ø160/700 XL katuseventilaator

Kirjeldus: Soojustatud XL katuseventilaator. Sisemine toru on tsingitud plekist ja varustatud tihendiga. Sobiv VILPE XL läbiviik vastavalt katusematerjalile tuleb hankida eraldi.

Mõõtmed: Toru Ø 160 mm, välimine Ø 300 mm, kõrgus katusest u 700 mm.

Sisaldab: Katuseventilaator, kruvid, paigaldus-, kasutus- ja hooldusjuhend.
Color
Product number734512
LVI Code7813662
EAN Code6410457345120
Color | RR33 | RAL9005
Weight Gross: 9.801kg, Net: 8.499kg
Product number734514
LVI Code7813664
EAN Code6410457345144
Color | RR32 | RAL8019
Weight Gross: 9.801kg, Net: 8.499kg
Product number734516
LVI Code7813666
EAN Code6410457345168
Color | RR11
Weight Gross: 9.606kg, Net: 8.197kg
Product number734517
LVI Code7813667
EAN Code6410457345175
Color | RR23 | RAL7024
Weight Gross: 9.801kg, Net: 8.499kg
Product number734518
LVI Code7813668
EAN Code6410457345182
Color | RR29 | RAL3009
Weight Gross: 9.801kg, Net: 8.499kg
Product number734519
LVI Code7813669
EAN Code6410457345199
Color | RR750 | RAL8004
Weight Gross: 9.801kg, Net: 8.499kg
Product number73451D
EAN Code6410457657094
Color | RR2H3 | RAL7016
Weight Gross: 9.801kg, Net: 8.499kg
SKU: N/A Categories: ,
Share product page
Print pdf
Duct size160 Ø
Materialsexpanded polystyrene, galvanized sheet steel , polypropene plastic (PP)
Package includescowl, fixing screws
Voltage230V/50Hz
Current0,39 A
Rotation speed (rpm)2100 rpm
Capacitor2 µF
Power88 W
Fan typeAC

Performance data graphs

VILPE E220 - ISO 3471:1988 - ISO-5221:1984

Air density: 1.2

10V
180V
165V
135V
110V
60V
10V
180V
165V
135V
110V
60V
10V
180V
165V
135V
110V
60V

Download CAD Models

Download DWG-file
73451x.dwg
MagiCAD file

Materials & Installation
